1.MATERIAL
　　Insulator:High Temperature Thermoplastic,
　　UL94V-O
　　Contact:Copper Alloy
　　Shell:Copper Alloy
2.PLATING
　　Contact Area:Gold PLATED Over Ni.
　　Solder Tail:Sn PLATED Over Ni.
　　Shell Solder Arda:Gold PLATED Over Ni.
3.ELECTRICAL
　　Operating Temperature:-25℃ TO+90℃
　　Current Rating:0.5mA max.
　　Contact Resistance:100mΩ max.
　　Insulation Resistance:1000MΩ min./500VDC
